Solid Particles Impurities and Microorganisms Collect Filter Bag

Qingdao Star Machine is a Solid particles impurities and microorganisms collect Filter Bag manufacturers in china.Our filter bag filter media made of natural fibers or woven materials. To ensure our refining solid-liquid separation and catalyst recovery filter cloth product is sturdy and durable.To increase the service life of the filter cloth.Our Solid particles impurities and microorganisms collect Filter Bag have a good filtration performance, strict environmental standards, high precision, strong composite, acid, alkali, and high temperature resistance.If necessary, we can provide free samples.

Product Feature And Application

1.Polypropylene Solid particles impurities and microorganisms collect Filter Bag, also known as PP Solid particles impurities and microorganisms collect Filter Bag, is a bag shaped filter element made of polypropylene material.

Adopt ultrasonic fusion or wire stitching.

Sealing ring: Polypropylene and polyester SDS, STS, galvanized steel ring or stainless steel ring.

Sealing ring connection method: ultrasonic fusion or wire stitching.

Filter accuracy range: 1, 3, 5, 10, 25, 50, 75, 100, 150, 200 microns.

Efficiency: Relative accuracy, with a single filtration efficiency of 85%.

Surface treatment: A smooth surface treatment that prevents the separation of fibers and dissolved substances.

Material grade: Fully compliant with FDA grade requirements, free from silicon and other types of pollutants.

The replacement pressure difference should be 0.10MPa, and the replacement pressure difference should not exceed 0.18MPa.

Wide chemical compatibility.

2. Due to the unique nature of the material, PTFE material Solid particles impurities and microorganisms collect Filter Bag can withstand harsh operating conditions without being affected by any environment. It is a high temperature, strong acid, alkali, and high-precision filter choice for many chemical industries.

High temperature resistance - operating temperature up to 250°C.

Low temperature resistance - has good mechanical toughness, and can maintain an elongation of 5% even when the temperature drops to -196°C.

Corrosion resistance - shows inertness and resistance to strong acids, alkalis, water, and various organic solvents for most chemicals and solvents.

Climate resistance - has the best aging life among plastics.

High lubrication - refers to the low friction coefficient in solid materials.

Non adhesion - refers to the small surface tension in solid materials that does not adhere to any substance.

Electrical insulation - can withstand 1500 volts of high voltage.

3.Polyester Solid particles impurities and microorganisms collect Filter Bag (PE Solid particles impurities and microorganisms collect Filter Bag) is made of polyester fiber filter cloth. This product belongs to the dual interception mode, effectively removing solid and soft particles, that is, larger particle impurities are trapped on the surface of the fiber, while fine particles are captured in the deep layer of the filter material, ensuring that they will not be damaged due to pressure increase during use, and has high filtration efficiency.
