Precision Filtration Cloth

Qingdao Star Machine Technology Co.,Ltd. is a large-scale Precision Filtration Cloth manufacturer and supplier in China. We are located in Qingdao, Shandong, China, with convenient transportation conditions. We have three production and research and development bases and one product sales center. Our product cover most of the European, Asian and American markets. We look forward to becoming your long-term partner in China.

Send Inquiry

Product Description

Qingdao Star Machine Customized Precision Filtration Cloth should not be hung too loose or too tight, as being too loose can easily accumulate dust and being too tight can easily damage it.

New and old filter cloth should not be mixed to avoid damage at different times that may affect the normal operation of the equipment.

Wholesale Precision Filtration Cloth can be cleaned by water, and then checked for any damages. Any holes should be repaired and left for replacement. If the filter cloth is covered with dust, rinse it with water, cool it dry, and leave it for replacement. If necessary, we can provide free samples.

Product Parameter (Specification)

Model	Weaving	WEIGHT	Density (PC/10CM)		THICKNESS	Breaking Strength (N/5*20CM)		Elongation At Break (%)		Air Permeability
Model	Weaving	G/M²	Warp	Weft	MM	Warp	Weft	Warp	Weft	(L/M².S)
621	Polyester Long Fiber	340	192	130	0. 65	4380	3575	50	30	55
621B	Polyester Long Fiber	440	260	145	0. 78	4380	3575	50	30	60
120-14 (747)	Polyester Staple Fiber	248	226	158	0. 75	2244	1371	31	15	120
120-15 (758)	Polyester Staple Fiber	330	194	134	0. 73	2721	2408	44.2	21.3	100
120-16 (3927)	Polyester Staple Fiber	524	156	106	0. 90	3227	2544	60	23	25
	Polyester Needle Punched				1.80					18

Precision Filtration Cloth Feature And Application

The types of Precision Filtration Cloth products cover most industrial and mining industries, suitable for industrial and mining industries such as copper ore, nickel ore, iron concentrate, and lead zinc ore. High filtering accuracy, fine filtering less than 5μm. The ultrasonic automatic edge sealing process ensures that the edges of the filter cloth are not easily peeled off.
